Material | Stahl |
Max. Betriebsüberdruck | 10 bar |
Max. Betriebstemperatur | 90 °C |
Horizontale/waagerechte Variante | nein |
Betrieb | - Rein hydraulisch (nur Wasser) |
Lieferzeit | 4-8 Wochen |
Individuelle Fertigung (auf Maß) | nein |
Kode | B x H x T [mm] |
Q [W] (75/65/20°C) |
Anschlussmass [mm] |
Volumen [l] |
Gewicht [kg] |
Preis (ohne MwSt.) |
---|---|---|---|---|---|---|
RA1-320920500VW | 92 x 500 x 106 | 120 | 610 | 0.3 | 2.3 | 321 € |
RA1-320921000VW | 92 x 1000 x 106 | 296 | 1110 | 0.7 | 5 | 439 € |
RA1-320921500VW | 92 x 1500 x 106 | 472 | 1610 | 1 | 7.8 | 556 € |
RA1-320922000VW | 92 x 2000 x 106 | 626 | 2110 | 1.3 | 10.5 | 674 € |
RA1-320922500VW | 92 x 2500 x 106 | 746 | 2610 | 1.6 | 13.2 | 787 € |
RA1-320923000VW | 92 x 3000 x 106 | 922 | 3110 | 1.9 | 15.9 | 904 € |
RA1-571370500VW | 137 x 500 x 154 | 157 | 610 | 1.1 | 4.6 | 389 € |
RA1-571371000VW | 137 x 1000 x 154 | 330 | 1110 | 2.1 | 9.1 | 525 € |
RA1-571371500VW | 137 x 1500 x 154 | 539 | 1610 | 3.1 | 13.7 | 660 € |
RA1-571372000VW | 137 x 2000 x 154 | 732 | 2110 | 4.1 | 18.2 | 796 € |
RA1-571372500VW | 137 x 2500 x 154 | 810 | 2610 | 5.1 | 22.7 | 931 € |
RA1-571373000VW | 137 x 3000 x 154 | 1135 | 3110 | 6.2 | 27.2 | 1.067 € |
RA1-571374000VW | 137 x 4000 x 154 | 1545 | 4110 | 8.2 | 31.7 | 1.793 € |
RA1-571375000VW | 137 x 5000 x 154 | 1947 | 5110 | 10.3 | 40.7 | 2.168 € |
RA1-571376000VW | 137 x 6000 x 154 | 2311 | 6110 | 12.3 | 49.6 | 2.543 € |
RA1-761560500VW | 156 x 500 x 173 | 174 | 610 | 2 | 5.4 | 434 € |
RA1-761561000VW | 156 x 1000 x 173 | 347 | 1110 | 3.9 | 10.7 | 592 € |
RA1-761561500VW | 156 x 1500 x 173 | 555 | 1610 | 5.8 | 16.1 | 746 € |
RA1-761562000VW | 156 x 2000 x 173 | 745 | 2110 | 7.7 | 21.5 | 900 € |
RA1-761562500VW | 156 x 2500 x 173 | 840 | 2610 | 9.7 | 26.9 | 1.058 € |
RA1-761563000VW | 156 x 3000 x 173 | 1210 | 3110 | 11.6 | 32.3 | 1.211 € |
RA1-761564000VW | 156 x 4000 x 173 | 1610 | 4110 | 15.4 | 37.7 | 2.042 € |
RA1-761565000VW | 156 x 5000 x 173 | 1992 | 5110 | 19.3 | 46.7 | 2.462 € |
RA1-761566000VW | 156 x 6000 x 173 | 2361 | 6110 | 23.1 | 56.9 | 2.886 € |
URL Adresse: https://laurens-heizkoerper.de/spiralix-single-vertical-de
Datenblatt: https://laurens-heizkoerper.de/download/de/tech/spiralix-vetrikal-ra1-de.pdf
Projektunterlagen für Planer und Architekten: https://laurens-heizkoerper.de/download-von-unterlagen-de#spiralix
